CNC Lathe

CNC LATHE

  • Specifications include TC25 / 30A / 35A / 40A
  • High hardness and high stability
  • Maintain high accuracy
  • Heat balance of spindle
  • High efficiency and heavy cutting properties

ACCURATE TO POINTS

CNC Lathe - Hision CNC using advanced technology to meet the needs of customers. The product has high rigidity, heavy machining with high stability.

The new generation CNC lathe is monolithic, designed to increase rigidity through new scientific technology, minimizing thermal deformation and torsion resistance, helping the machine maintain long-term accuracy and heat. stable.

HIGH STABILITY AND STABILITY

HIGH STABILITY AND STABILITY

The integrated 45° inclined L-shaped body is highly modal and impact resistant to provide the high rigidity of the lathe.



HIGH ACCURACY MAINTENANCE

HIGH ACCURACY MAINTENANCE

The body and the Sliding System use panel tape, surface tempered then abrasive treatment, the sliding surface is affixed with wear-resistant protective belts, minimizing friction while avoiding deformation, ensuring and maintain high accuracy.

EQUALIZE THERMAL HEAT



  EQUALIZE THERMAL HEAT

  Spindle box and slide seat are installed on the same angular plane to reduce deformation caused by thermal deformation of spindle box and ensure thermal balance of spindle.

High efficiency and heavy cutting properties



High efficiency and heavy cutting properties

The spindle has a high fox rigidity and a long hard rail together with a 12-position hydraulic turret, ensuring that the machine tool is highly efficient and has heavy cutting properties.

CNC lathe operation process

Hision TC25IIx500 / TC25IIX1000 CNC Lathe

Lathe machine TC25Ⅱ

TECHNICAL SPECIFICATIONS

  • XY 210 / 610mm
  • Turning diameter: not 400mm
  • Lathe length: 548mm -1000mm
  • Spindle speed: 4500rpm
  • Knife tower: 12T (size 40mm - 25 × 25 square)
  • Operating System: Fanuc 0i TF Plus
